11.6寸EDP 30 PIN IPS 1920*1080分辨率 TFT LCD LCM液晶顯示屏

類別：11.6寸液晶顯示屏

簡介：

MTF116FD06A-V1

全國咨詢服務熱線:136 0302 8193

立即購買在線咨詢

產品介紹
相關產品

1.1 Introduction MTF116FD06A-V1 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a driving circuit.This TFT LCD has a 11.6 inch diagonally measured active display area with (1920 horizontal by1080 vertical pixe l) resolution.

1.2. Features 11.6 inch configuration ROHS design

1.3. General information

Item	Specification
Outline Dimension	267.90(H) x157.22 (V) x2.60(D) mm
Display area	256.32(H) x 144.18(V) mm
Number of Pixel	1920RGB (H) x 1080 (V) pixels
Pixel pitch	0.1335(H) x 0.1335(V)s mm
Pixel arrangement	RGB Vertical stripe
Display mode	AHVA, Normally Black IPS
Color Filter Array	RGB vertical stripes
Backlight	White LED
Weight	TBD
Electrical Interface	EDP
